Hualian Horizontal Continuous Band Sealer with Ink-jet Printing and Coding function FRP-770I

Availability:
Quantity:
  • FRP-770I
  • Hualian
  • Bags
  • Seal

Product Description

Description:
FRP-770 smart Ink-jet Printing Sealer is applicable to the sealing of small packages. The code spraying control operating system adopts the Linux operating system, which is free to open source. It is widely used worldwide with good portability, extremely stable system, extensibility and long-time steady running. Customers can freely adjust the size and length of the printing font according to their own demands, and the machine has sealing counting function and rich inject-printing content.

Features:
One machine with two function, One machine meets printing and sealing. Linux Touch Screen Operating System, free to open source, adopt Quad-core High-performance Processor, Main frequency hits 1.5GHz. Extremely Fast Response, Smooth Operation   Flat interface design, simple and beautiful, operation guide with scroll tips, interactive friendly; 5 inch IPS HD capacitive touch screen, display resolution reaches to 800x480, shown delicately, colorfully, visual angle is to be close to 180; Exclusive on the market with dual intelligent input method, supporting associating inputting of Chinese and English, handwriting, five stroke, Tsang-jei input method etc., more efficient editing. The corresponding language input method can be automatically switched according to the system language. Supporting directly inputting picture format in: bmp, jpg, png etc., any graphic element can be dragged and zoomed to be adjusted size, exempting formatted tedious operation from computer; Unique font management function, personal favorite fonts can be lead in by user. Various printing Content, can Print text、date、mark、LOGO image、QR code、Barcode, etc. One-click switching,more than 20 kinds of languages supporting(including the corresponding language input method), supporting any customized language; Have WiFi networking,Software Online Updating、USB flash disk updating,continuous maintenance and optimization; When charged, the cartridge can be plugged or removed at will.

Parameters

MODELFRP-770I
Sealing Width10mm
Voltage (V/Hz)AC 220/50
Heating Power300W*2
Motor Power (W)50/100W
Temperature Range0-300℃(Adjustable)
Sealing Speed (m/min)0-16(0-24)
Distance from Sealing Center to Conveyor10-40mm
Printing typeHot foaming inkjet
Distance from Base Plate to Interior Conveyor60-120mm
Conveyor SizeL 844 X W 153mm
Max. Distance from Sealing Center to the Mouth of Bag21mm
Consumables Replacement MethodLock / Open
Overall Conveyor Load/
External Dimensions844 X 375 X 425mm
Operation SystemLinux
Touch Screen Size5 Inch Capacitance Screen
Touch Screen Resolution800×480
Processor
Quad-core High-performance Processor
Max. Main Frequency 1.5GHz
Extremely Fast Response, Smooth
Internal Memory1G+4G
NozzleTIJ2.5Hot foaming inkjet Sprinkler
Inject-Printing Font Height1.5-12.7mm
Printing LengthUnlimited
Max.Printing Lines6lines
Ink Type & CapacityOiliness/42ml
Ink ColorBlack(standard)/Red/Green/Blue/Yellow/White/Transparent
Inject-Printing Material
Suitable for Any Composite Film Material
Special Material Need Customized Ink
Languages in Touch ScreenChinese, English, Arabic, Turkish, Spanish, Portuguese, Korean, Russian (support customization)
Inject-Printing Content
Chinese, English, Digital, Symbols, Graphics (support any image without conversion format), QR Code, Bar Code (custom barcode
content, system real-time variable barcode), Variable Date (system custom), Variable Count (system custom), Variable QR Code (jet
printing system with real-time variable data , customized online system)
Ink-jet Printing CountCount 0-100000
Ink Cartridge Printing VolumeAbout 200 thousand(refer to the Production Date of 4mm*30mm(Height*Length)
Inject-Printing Content StorageStore 200 bars(Individual count storage function for each bar printing content)
Inject-Printing FontAdjustable(support customized printing font)
External TerminalUSB/RS232 serial Terminal/WIFI
Online OperationOptional(One host can control 1+N units)
Adjustable Startup InterfaceOptional
