L Type Side Sealing Machine For Small Commodities With Touch Screen BSF-5640LG

Availability:
Quantity:
  • BSF-5640LG
  • Hualian

Description

BSF-5640LG Automatic L Bar Sealer is mainly applied to film wrapping for different products, which has the advantages of dustproof, damp-proof and beautiful sealing.



Features:

Widely applied to different kinds of products

The economical model which is the best choice for getting started with an automatic sealer

Equipped with safety protection cover and alarm device

Automatic feeding, whose length can be automatically adjusted by a combination of sensor and timer

Perforator device can be flexibly adjusted

Design of brush is for permanent use

Sealing temperature is controlled by PID system

Integrated L shaped sealing blades coated with Teflon.



Application:

1. BSF-5640LG Automatic L Bar Sealer is applied to heat shrinkable film such as PVC, POF, PP, etc.

2. it is suitable for single and combinations packages such as cookies, books, CDs, glassware, tissue, paper card, photo frame, aluminum section, woodwork, etc.

3. To use in the place where there is enough space, such as factory and warehouse, etc.


Parameters

MODELBSL-5640LG
Voltage (V/Hz)220V 50/60HZ
Air Pressure Required (kg/cm³)5-8
Power (kw)1.8
Capacity (PCS/min)0-25
Max. Packing Size (mm)W+H<450,W<400,H<120,L<350
Max. Sealing & Cutting Size (L×H) (mm)500×400
External Dimension (L×W×H) (mm)1770×830×1600
Net Weight (kg)300


Product Detail

1 (1)1 (2)1 (3)1 (4)1 (5)1 (6)1 (7)1 (8)1 (9)1 (10)1 (11)1 (12)5 局部图上框

6BSF-5640LG局部新

热缩封切机包装样品图


9 产品包装
