Automatic Wrap Shrink Tunnel with Tray BS-4525A

Availability:
Quantity:
  • BS-4525A
  • Hualian

Description

BS-A series shrink tunnel adopts hot-wind & down-cyclone structure, intelligence temperature control and AC variable speed regulation. There are two optional conveyors, including Teflon belt type and roller type.



Features:

Manual regulation of conveyor height

Double adjustable air flap

Single independent heating room

Emergency off switch



Application:

1. BS-A series shrink tunnel is applied to heat shrinkable film such as PVC, POF, PP etc.

2. To shrink wrapping several products, such as food, beverage, cosmetics, presswork and toy etc.

3. To use in place where there is restictin on space, such as small factory, monplization shop and laboratory etc.


Parameters

MODEL

BS-4525A

Voltage(V/Hz)

220/50 380/50(3PH) 220/60(3PH)

Power(kw)

6.5

Loading(kg)

10

Speed(m/min)

0~10

Tunnel Size (L×W×H)(mm)

900×450×(50-250)

External Dimensions(L×W×H)(mm)

1200×650×1100

Net Weight(kg)

90



Product Detail

Hualian Shrinking Packaging Machine

詳情英文_02

詳情英文_03

詳情英文_04

詳情英文_05

詳情英文_06

詳情英文_07

詳情英文_08

詳情英文_09

詳情英文_10

詳情英文_11

詳情英文_12

詳情英文_13
