Automatic Electric Side Sealing Packaging Machine BSF-5545LD+BS-5030X

  • BSF-5545LD+BS-5030X
  • Hualian


BSF-5545LD High-Speed Side Sealing Machine is available with centerfold film to seal three sides, it adopts automatically or manually feed type, it suitable for fully automatic shrink wrapping.


BS-5030X High-Speed ShrinkTunnel is suitable for fully automatic shrink wrapping with high speed.


BSF-5545LD High-Speed Side Sealing Machine

Continuous side sealing without product length limit

High packing speed can reach 40-60 pcs/minutes

Sealing system controlled by servo motor ensures accurate position and perfect sealing

Sealing knife with automatic protection function, effectively prevent mistakenly cutting object

Transparent window function can show shrinking process inside

It adopts a roll conveyor belt, also can adopt TEFLON mesh belt or stainless steel mesh belt.

Inner insulate shell, temperature uniformity.

Speed of conveying belt can be regulated at will by the electric speed controller.



1. BSF-5545LD High-Speed Side Sealing Machine + BS-X series shrink tunnel are applied to heat shrinkable film such as PVC, POF, PP, etc.

2. It is suitable for single and combinations package such as cookies, books, CD, glassware, tissue, paper card, photo frame, aluminum section, woodwork, etc.

3. To use in the place where there is enough space, such as factory and warehouse, etc.


Voltage (V/Hz)3 Phase   380/50  or  3 Phase 220/60
Compressed Air (kg/cm3)44355
Power (kw) 3
Capacity (pcs/min) 0-40

Max. Packing Size (W+H) (mm)

W+H≤450,W<350 Length unlimited
Max. Packing Height (mm)150
Sealing Length (mm)450
External Dimension (L×W×H) (mm)2040×1480×1350
Net Weight (kg)800

Voltage (V/Hz)3 Phase380/50  or  3 Phase 220/60
Power (kw)16
Max. Packing Size (W×H) (mm)400×250
Speed (m/min)0~25
Tunnel Size (L×W×H) (mm)1500×500×300
External Dimensions (L×W×H) (mm)1800×990×1300
Net Weight (kg)300
